- - Soft start ready - 4 Poles Brushless Motor Technology for the Ultimate Power & Control
- - Ultra Precise, High Resolution Control - Fully Replaceable Hardend Steel Gear Train for Maximum Strength
- - Excellent Thermal Dissipation via Finned 6061 Aluminum Case - 8.4V High Voltage Ready
- - Optimized for Airplane & Jet Aircraft - Water proof IP65 - Dual Ball Bearing Construction
Speed:
0.11 sec / 60° @ 8.4V
0.12 sec / 60° @ 7.4V
0.14 sec / 60° @ 6.0V
Torque:
82Kg.cm / 1138.76 oz in. @ 8.4V
75Kg.cm / 1041.55 oz in. @ 7.4V
65Kg.cm / 902.68 oz. in. @ 6.0V
Specifications:
Motor Type: Brushless
Servo Arm Type: Futaba
Working Frequency: 1520us / 333Hz
Weight: 70gr
Dimensions: 40.5mm x 20mm x 38mm (LxWxH)
Voltage Range: 6.0V - 8.4V
